Intel 915GM Express Chipset |
Intel 855GME Chipset |
|
Processor Supported |
Pentium?M, Celeron?M |
Pentium?M, Celeron?M |
|
FSB Speed |
533MHz/400MHz |
400MHz |
|
Memory Type |
DDR2 400/533, |
DDR 333/266/200 |
|
DDR 333 1 ch |
|
Memory Channels |
Dual/Single Channel |
Single Channel |
|
Integrated Graphics |
Intel GMA 900, |
Integrated 32-bit 3D/2D gfx core with Dynamic Video Memory Technology |
|
(200/222/333 MHz @ 1.5v) , |
|
(190/200/213/222 MHz @ 1.05v) |
|
Discrete Graphics |
PCIe x16 |
AGP4x (discrete graphics only) |
|
Integrated TV Out |
Yes |
N/A |
|
Max Panel Display Resolution |
LVDS: Up to UXGA (1600x1200), |
LVDS: Up to UXGA (1600x1200), |
|
Digital/Analog Converter for CRT: QXGA (2048x1536) |
Digital/Analog Converter for CRT: QXGA (2048x1536) |
|
Intel Display Power Savings Technology |
Yes |
N/A |
|
PCI Masters |
7 PCI Masters |
6 PCI Masters |
|
IDE / SATA |
1 x ATA 100 |
ATA 66/100 |
|
2 x SATA |
|
USB |
8 x USB 2.0 |
6 x USB 2.0/1.1 |
|
PCI Express I/O Ports |
Four PCIe x1 |
N/A |
|
Audio Circuitry |
Intel?High Definition Audio 24-bit 192KHz, AC'97 2.3 Audio |
Integrated AC'97 controller, 6 channels |
