> 产品 > ETX 模块 > ICE-DB-T6R| ● Intel® 22nm Atom™ or Celeron® on-board SoC supported |
| ● Intel® HD Graphics Gen7 integrates high-performance graphics and media processing |
| ● Supports 1333/1066 MHz DDR3L (1.35V) memory, up to 8 GB |
| ● Supports one analog CRT, one 24-bit dual-channel LVDS, and one DDI |
| ● Optional soldered down 4 GB SSD |
| ● IEI One Key Recovery solution allows you to create rapid OS backup and recovery |
产品规格
| Display Output | 1 x VGA 1 x HDMI (HDMI signal only) |
| 1 x DisplayPort pin-header 1 x DisplayPort connectors | |
| 1 x LVDS 18/24-bit single or dual-channel (with PWM back light controller) | |
| CPU | Supports COM Express Compact/Mini module using connector pin out Type 6 |
| Storage | EEPROM (supports EAPI R1.0) |
| Expansion | 1 x PCIe x16 |
| 5 x PCIe x1 | |
| 1 x LPC | |
| 2 x PCIe Mini (MINIPCIE1 colay with m-sata with SATA_4) | |
| Operating Temperature | -20°C ~ 60°C |
| Humidity | 5% ~ 95 non-condensing |
| I/O Interface | 2 x USB 2.0 |
| 2 x USB 3.0 |
订购信息
| ICE-DB-T6R-R10 | Base Board for COM Express Type 6 Module COM.0 Rev. 2.1,support PICMG EAPI R1.0 |
